What a user layout is
A user layout is the saved definition of the columns used by a product list. Use Layout to maintain that definition and its columns. Filtering and exporting belong on the User layouts page.
| If you need to… | Go to |
|---|---|
| Open an existing layout | User layouts |
| Review the saved fields and status flags | Record and layout fields |
| Compare the user layout with the default layout | Parsed layout areas |
| Parse or reconcile the saved layout text | Maintain the layout text and compare defaults |
| Add, edit, or remove a layout column | Maintain layout columns |
| Maintain default layouts | Default layouts |
Before you start
Open an existing user-layout record before maintenance begins. You need a live account and an existing record.
Find and open the layout
The Users layouts page is the list entry point for opening a saved user-layout record. The list page text includes Configuration, Default layouts, Users layouts, and Tickets.
Prerequisites
- You are signed in with access to the Users layouts list.
- A saved layout record is available in the list.
Steps
- Open Users layouts from the configuration area.
- Locate the saved layout record.
- In that record's row, select the available edit action.
The edit action is available for records in the same branch as the account.
Result: The selected record opens on the Edit user layout page when its row has the edit action.
Understand the edit surface
The edit surface combines the record area, the saved layout text, two layout grids, and column actions. The user layout grid helps you inspect the columns in the saved definition. The default layout grid provides the comparison and reconciliation area. Use the column controls to change a selected column. Confirm before removing a column.
| Surface | Reader job |
|---|---|
| Record area | Review the layout identity and status flags. |
| Layout text | Read or change the required Layout text. |
| Parsed user layout | Inspect and maintain the columns represented by the saved layout. |
| Parsed default layout | Compare the saved columns with the default columns and reconcile them. |
| Column settings | Change one selected column. |
| Deletion prompt | Confirm before removing the selected column. |
Record and layout fields
The record fields identify the saved layout and supply its layout text. Identity fields identify the saved layout; status fields show its state. Both groups are disabled. Layout is the required text area used for layout maintenance.
| Field | Type | Required | Availability |
|---|---|---|---|
| Name | Text | Yes | Disabled |
| List num | Select | Yes | Disabled |
| Is current | Boolean | No | Disabled |
| Is standard | Boolean | No | Disabled |
| Layout | Text area | Yes | Used for layout text maintenance |
List choices
The disabled List num field displays these choices. The column editor uses the data-type and filter-operation choices shown after it.
| List num option | ID |
|---|---|
| Activities (0) | 0 |
| Tasks (1) | 1 |
| Contract (2) | 2 |
| Registeration data (3) | 3 |
| Ticket - Running (4) | 4 |
| Ticket - Closed (5) | 5 |
| Layouts (6) | 6 |
| Pricing indicator (7) | 7 |
| Project (21) | 21 |
| Clients (22) | 22 |
| Principals (23) | 23 |
| Roles (26) | 26 |
| Users (27) | 27 |
| Account (29) | 29 |
| Contact (30) | 30 |
| Invoices all (31) | 31 |
| Payment (32) | 32 |
| Sales Leads(39) | 39 |
| Sales All(40) | 40 |
| Sales Inquiries (41) | 41 |
| Sales Offers (42) | 42 |
| Sales Orders (43) | 43 |
| Sales Delivered (44) | 44 |
| Sales Lost offer (45) | 45 |
| Sales Regretted (46) | 46 |
| Sales Deleted (48) | 48 |
| Sales Rejected orders (49) | 49 |
| Sales Missed Inquiries (50) | 50 |
| Sales Cancelled offer (51) | 51 |
| Sales Cancelled order (52) | 52 |
| Buyout All (53) | 53 |
| Buyout RFQ (54) | 54 |
| Buyout Offer (55) | 55 |
| Buyout Order (56) | 56 |
| Buyout Delivered (57) | 57 |
| Buyout Rejected offer (58) | 58 |
| Buyout Regretted (59) | 59 |
| Buyout Deleted (61) | 61 |
| Buyout Rejected order(62) | 62 |
| Buyout Cancelled offers (64) | 64 |
| Buyout Cancelled order (65) | 65 |
| Principal invoice (67) | 67 |
| teams (70) | 70 |
| Account managers (71) | 71 |
| Subscription Invoices (72) | 72 |
| Letter of guarantees all (73) | 73 |
| Products (74) | 74 |
| MRQ (75) | 75 |
| Procurement All (76) | 76 |
| Procurement RFQ (77) | 77 |
| Procurement Offer (78) | 78 |
| Procurement Order (79) | 79 |
| Procurement Delivered (80) | 80 |
| Procurement Rejected (81) | 81 |
| Procurement Regretted (82) | 82 |
| Procurement Deleted (83) | 83 |
| Procurement Rejected order (84) | 84 |
| Procurement Cancelled offers (85) | 85 |
| Procurement Cancelled orders (86) | 86 |
| Extension rejected offer (89) | 89 |
| Warehouse configuration (91) | 91 |
| Receiving shipment (92) | 92 |
| Inspection (93) | 93 |
| PM All (94) | 94 |
| PM Planned To Order (BOM) (95) | 95 |
| PM Ready To Order (MRQ) (96) | 96 |
| PM In Procurement All (97) | 97 |
| PM In Procurement Inquiry (98) | 98 |
| PM In Procurement Offer (99) | 99 |
| PM In Procurement Order (100) | 100 |
| PM In Procurement Stuck (101) | 101 |
| PM Products Receipt (102) | 102 |
| PM Product Rejected (103) | 103 |
| PM Stored (104) | 104 |
| PM Assembly (105) | 105 |
| PM Loss (106) | 106 |
| PM Ready For Shipment (107) | 107 |
| PM Delivered (108) | 108 |
| Stock (109) | 109 |
| Packages (110) | 110 |
| upcoming stock (111) | 111 |
| Production order (112) | 112 |
| Shipping order (113) | 113 |
| Issue goods note (114) | 114 |
| External service order (115) | 115 |
| Transfer order (116) | 116 |
| Return note (117) | 117 |
| Delivery note (118) | 118 |
| PM orders (119) | 119 |
| In-warehouse all (120) | 120 |
| PM Delivered orders (121) | 121 |
| Reference list by serial num. (122) | 122 |
| Job Profitabilty (123) | 123 |
| Job Cost Transaction (124) | 124 |
| Purchase Invoice (125) | 125 |
| Outgoing Paymnet (126) | 126 |
For a column's Type, the editor offers string, number, date, and boolean as
the product's column data types. For Selected filter operation, it offers contains,
Does not contain, Starts with, Ends with, Equals, and Not equals as product
filter operations.
Parsed layout areas
The user layout grid appears when it contains layout columns. It has the following columns.
| Parsed user layout columns |
|---|
| Index, Field, Type, Caption, Visible, Width |
The default layout grid appears when it contains layout columns. It has Index, Field, Type, Caption, and Visible. The grid does not include a column for numbering rows.
Column editor fields and choices
The new-column and edit-column popup contains the following fields.
| Field or control | Type | Required | Rule or choice |
|---|---|---|---|
| Column text area | Text area | Yes | Required |
| Index | Text | Yes | Disabled |
| Visible | Boolean | No | Optional |
| Field | Text | Yes | Required |
| Type | Select | Yes | Required; use the four product data types above |
| Caption | Text | No | Optional |
| Width | Number | No | Optional; minimum 0 |
| Filter value | Text | No | Optional |
| Selected filter operation | Select | Yes | Required; use the six product filter operations above |
Maintain the layout text and compare defaults
Use this section when the saved layout text needs to be inspected or reconciled with the default layout. The two grids give you a row-based view of the layout; Layout remains the saved text area.
Prerequisites
- You have opened an existing layout record.
- The Layout field contains the layout text you need to review.
Steps
- Select Parse to display the Layout columns in the user layout grid.
- Review the user layout columns.
- Select Stringfy to copy the user layout grid back into Layout.
- In the default layout area, select Clean user layout to remove duplicate or unmatched user columns.
- Select Update user layout to add missing default columns and update matching column metadata.
- Review the two layout grids again.
Result: Layout contains the user layout grid after Stringfy. The comparison actions clean or update the user columns according to the selected action.
Maintain layout columns
Use the column actions when a layout needs a new column, a change to a selected column, or removal of a selected column.
Prerequisites
- You have opened a parsed user or default-layout grid.
- You know which row and column property you need to maintain.
Steps
-
Select the row's Edit column action to open the column editor.
-
In the column editor, enter or choose the required values.
-
Select Save in the column editor.
-
To remove a selected column, select its Delete column action and choose an outcome at
Are you sure?.If you need to… Select Keep the column No Confirm removal Yes
Result: The updated column appears in the layout, or the column is removed.
When maintenance goes wrong
Use the message text to match the problem to the action you just took.
| What you see | Condition or action |
|---|---|
This Field Is Required | A required field has no value. Check Layout or the required column-editor fields. |
Your request was completed successfully | The save request reports success. |
An error occurred while processing your request | The request reports an error. |
Are you sure? | A delete-column confirmation is open. Choose No or Yes. |
Save and Save and Close are available after a change. Close opens the exit choices when changes exist and leaves directly when there are no changes.
What to do next
When the layout is ready, choose the outcome that matches your next task.
Prerequisites
- You have finished reviewing the layout and its columns.
- You know whether the current changes must be saved.
Steps
-
Choose one outcome.
If you need to… Select Save the layout and remain on the page Save Save the layout and leave the page Save and Close Attempt to leave the page Close -
If the exit popup appears after Close, choose an exit outcome.
If you need to… Select Leave without saving Don't Save Keep the changes and close the popup Cancel
Result: Save saves the layout and keeps you on the page. Save and Close saves
the layout and leaves the page. Close attempts to leave the page. After a successful
save, the message is Your request was completed successfully.
Continue with User layouts, Default layouts, or the related default-layout configuration.
