Export diagrams to files

Use the live DiagramInstance to export the mounted diagram as a PNG, SVG, or PDF. The export contains the rendered scene graph rather than a screenshot: labels, edges, arrowheads, and effects remain part of the output.

Before you export

Mount a non-empty diagram and give its host a size. The following JavaScript example renders three nodes, then downloads a 2× PNG, an SVG, and a vector PDF.

ts
import { render } from '@grafloria/element';

const host = document.getElementById('diagram')!;
host.style.height = '400px';
const instance = render({
  nodes: [
    { id: 'requirements', label: 'Requirements', position: { x: 60, y: 90 }, size: { width: 190, height: 78 } },
    { id: 'design', label: 'Design', position: { x: 340, y: 90 }, size: { width: 190, height: 78 } },
    { id: 'ship', label: 'Ship', position: { x: 620, y: 90 }, size: { width: 190, height: 78 } },
  ],
  edges: [
    { id: 'requirements-design', source: 'requirements', target: 'design' },
    { id: 'design-ship', source: 'design', target: 'ship' },
  ],
}, host);

instance.renderNow();

function download(href: string, name: string): void {
  const link = document.createElement('a');
  link.href = href;
  link.download = name;
  link.click();
}

async function downloadFiles(): Promise<void> {
  download(await instance.export('png', { scale: 2 }), 'diagram.png');

  const svg = await instance.export('svg');

  download(await instance.export('pdf'), 'diagram.pdf');
}

void downloadFiles();

export() returns a promise. PNG and PDF results are data URLs; SVG is raw SVG source, so wrap it in an encoded data URL before downloading. Call it after the first paint; renderNow() makes that paint synchronous.

Option	Type	Default	What it does
`format`	`'png' \| 'jpeg' \| 'webp' \| 'svg' \| 'pdf'`	—	Selects the output format.
`scale`	number	—	Sets the raster export scale, such as `2` for a 2× PNG.
`embedModel`	boolean	—	Embeds the diagram document in an SVG or PNG so the artifact can be reopened as an editable diagram.

Export from framework bindings

The binding supplies the same instance through its initialization callback. Keep that instance in framework state or a ref, and call export() from the button handler.

js
import { render } from '@grafloria/element';

const host = document.getElementById('diagram');
if (!host) throw new Error('Missing #diagram');
host.style.height = '400px';
const instance = render({
  nodes: [
    { id: 'a', label: 'Requirements', position: { x: 60, y: 90 }, size: { width: 190, height: 78 } },
    { id: 'b', label: 'Design', position: { x: 340, y: 90 }, size: { width: 190, height: 78 } },
  ],
  edges: [{ id: 'e1', source: 'a', target: 'b' }],
}, host);

instance.renderNow();

async function downloadPdf() {
  const pdf = await instance.export('pdf');
  const link = document.createElement('a');
  link.href = pdf;
  link.download = 'requirements.pdf';
  link.click();
}

void downloadPdf();

ts
import { Component, viewChild } from '@angular/core';
import { DiagramCanvasComponent } from '@grafloria/angular';

@Component({
  standalone: true,
  imports: [DiagramCanvasComponent],
  template: `
    <button (click)="downloadPdf()">download PDF</button>
    <grafloria-diagram-canvas [(nodes)]="nodes" [(edges)]="edges" style="display:block;height:400px" />
  `,
})
export class ExportDiagramComponent {
  canvas = viewChild.required(DiagramCanvasComponent);
  nodes = [
    { id: 'a', label: 'Requirements', position: { x: 60, y: 90 }, size: { width: 190, height: 78 } },
    { id: 'b', label: 'Design', position: { x: 340, y: 90 }, size: { width: 190, height: 78 } },
  ];
  edges = [{ id: 'e1', source: 'a', target: 'b' }];

  async downloadPdf(): Promise<void> {
    const href = await this.canvas().exportDiagram('pdf');
    const link = document.createElement('a');
    link.href = href;
    link.download = 'requirements.pdf';
    link.click();
  }
}

tsx
import { component$, $, noSerialize, useSignal } from '@builder.io/qwik';
import { GrafloriaFlow, type DiagramInstance } from '@grafloria/qwik';

const nodes = [
  { id: 'a', label: 'Requirements', position: { x: 60, y: 90 }, size: { width: 190, height: 78 } },
  { id: 'b', label: 'Design', position: { x: 340, y: 90 }, size: { width: 190, height: 78 } },
];
const edges = [{ id: 'e1', source: 'a', target: 'b' }];

export default component$(() => {
  const instance = useSignal();
  return (
    <div>
      <button onClick$={$(async () => {
        const href = await instance.value!.export('pdf');
        const link = document.createElement('a');
        link.href = href;
        link.download = 'requirements.pdf';
        link.click();
      })}>download PDF</button>
      <GrafloriaFlow defaultNodes={nodes} defaultEdges={edges} style={{ display: 'block', height: '400px' }} onInit$={$((api: DiagramInstance) => { instance.value = noSerialize(api); })} />
    </div>
  );
});

tsx
import { useRef } from 'react';
import { GrafloriaFlow } from '@grafloria/react';
import type { DiagramInstance } from '@grafloria/react';

const nodes = [
  { id: 'a', label: 'Requirements', position: { x: 60, y: 90 }, size: { width: 190, height: 78 } },
  { id: 'b', label: 'Design', position: { x: 340, y: 90 }, size: { width: 190, height: 78 } },
];
const edges = [{ id: 'e1', source: 'a', target: 'b' }];

export default function ExportDiagram() {
  const instance = useRef(null as DiagramInstance | null);
  const downloadPdf = async (): Promise<void> => {
    const href = await instance.current!.export('pdf');
    const link = document.createElement('a');
    link.href = href;
    link.download = 'requirements.pdf';
    link.click();
  };
  return <div><button onClick={downloadPdf}>download PDF</button><GrafloriaFlow defaultNodes={nodes} defaultEdges={edges} style={{ display: 'block', height: 400 }} onInit={(api) => { instance.current = api; }} /></div>;
}

vue
<script setup lang="ts">
import { GrafloriaFlow } from '@grafloria/vue';
import type { DiagramInstance } from '@grafloria/vue';

let instance: DiagramInstance | null = null;
const nodes = [
  { id: 'a', label: 'Requirements', position: { x: 60, y: 90 }, size: { width: 190, height: 78 } },
  { id: 'b', label: 'Design', position: { x: 340, y: 90 }, size: { width: 190, height: 78 } },
];
const edges = [{ id: 'e1', source: 'a', target: 'b' }];
async function downloadPdf(): Promise<void> {
  const href = await instance!.export('pdf');
  const link = document.createElement('a');
  link.href = href;
  link.download = 'requirements.pdf';
  link.click();
}
function onInit(api: DiagramInstance): void { instance = api; }
</script>

<template>
  <button @click="downloadPdf">download PDF</button>
  <div style="height:400px"><GrafloriaFlow :default-nodes="nodes" :default-edges="edges" style="height:100%" @init="onInit" /></div>
</template>

The mounted diagram shows Requirements connected to Design inside the sized canvas.

Each sample mounts a visible diagram and downloads requirements.pdf. Use 'png' or 'svg' in the same handler for raster or SVG output. Angular names the binding shortcut exportDiagram(format, options); the other bindings expose instance.export().

Choose editable or presentation output

PDF is a vector presentation file: text remains selectable and paths remain paths. It is not the editable Grafloria document format. To preserve editability, export SVG or PNG with embedModel: true:

ts
import type { DiagramInstance } from '@grafloria/renderer';

async function exportEditable(instance: DiagramInstance): Promise<void> {
  const editableSvg = await instance.export('svg', {
    embedModel: true,
    embedModelCreatedAt: '2020-01-01T00:00:00Z',
  });

  const editablePng = await instance.export('png', {
    embedModel: true,
    embedModelCreatedAt: '2020-01-01T00:00:00Z',
  });

  void editableSvg;
  void editablePng;
}

The embedded document carries the nodes, links, positions, and styling needed to reopen the artifact as a live diagram. A plain SVG or PNG without embedModel is a flat export. The editable round-trip demo shows the original and the reopened diagram side by side: open the live demo.

The reopened diagram is live beside the original, with its nodes and positions preserved.

See the result

Download image demo shows labels, arrowheads, shadows, and a 2× PNG.

The exported image preserves the node labels, arrowheads, and Transform node shadow.

PDF export demo shows selectable text and sharp vector paths.

The PDF diagram remains sharp while its Requirements, Design, and Ship labels remain selectable.

Pitfalls

Do not call export() before the diagram has painted. Render first; otherwise export rejects instead of returning a blank image.
SVG is source text, not a data URL. Encode it when assigning it to an anchor.
A 2× scale applies to raster output. SVG and PDF remain vector outputs.
embedModel is the option that makes SVG and PNG reopenable as editable diagrams; PDF is for vector presentation.

For the complete export surface, see The DiagramInstance. For saving a document rather than exporting a visual artifact, see Save and restore diagrams.
